Manual Option Brass Ball Valve

Introduction to Brass Ball Valves

A brass ball valve is a type of quarter-turn valve that uses a spherical disc (the ball) to control the flow of water. The ball has a hole through the middle, and when the valve is in the open position, the hole aligns with the flow direction, allowing water to pass through. When the valve is closed, the ball is rotated 90 degrees, and the hole is perpendicular to the flow, effectively stopping the water.

Brass, an alloy of copper and zinc, is a preferred material for these valves due to its excellent mechanical properties and corrosion resistance. Brass ball valves are available in various sizes and configurations, making them suitable for a wide range of applications.

Welcome to contact IFAN, we are online 24 hours a day to answer your questions!

The casting or processing of the valve body of the copper ball valve is a multi-step process, which mainly involves the casting, processing and surface treatment. The following are the main steps and key processes of copper ball valve body casting or processing:

Casting process

Casting mold production:

• Making molds according to product drawings is the first step in casting. The precision and quality of the mold directly affect the quality of the casting.

Copper smelting water:

• The copper material is smelted to obtain copper water that meets the requirements. The temperature and composition of copper water need to be controlled during the smelting process to ensure the performance of the casting.

Mold filling:

• The melted copper water is injected into the mold through the gate, waiting for the copper water to solidify and form. In this process, it is necessary to ensure that the copper water is evenly distributed in the mold to avoid defects.

Casting cooling:

• After the copper water solidifies in the mold, it needs to be cooled. The control of cooling rate has an important effect on the internal structure and performance of castings.

Processing process

Roughing:

• The cast valve body is placed on the processing equipment for preliminary cutting, milling, drilling, turning and other rough processing operations to remove excess materials and burrs, and to meet the basic size requirements.

Heat treatment:

• Heat treatment of the valve body, such as quenching, tempering, etc., to improve its hardness and wear resistance. The heat treatment process requires strict control of temperature and time to avoid deformation or cracks.

Finishing:

• The valve body is finished, including grinding, polishing and other processes, to improve its surface finish and geometric accuracy. Finishing is very important to ensure the sealing performance and appearance quality of the valve body.

Surface treatment

Chrome plating, painting, anodizing, etc. :

• In order to improve the corrosion resistance and aesthetics of the valve body, surface treatment is usually carried out. Chrome plating is one of the most commonly used surface treatment methods, which can form a dense layer of chromium on the surface of the valve body to effectively prevent corrosion and wear.

Key technology

• Casting process: Casting process is the basic process of manufacturing copper ball valve body, including casting mold production, melting copper water, mold perfusion and casting cooling steps. The choice and control of casting process has a decisive influence on the quality and performance of castings.
• Processing technology: Processing technology is a key link to ensure the dimensional accuracy and surface quality of the valve body. Including roughing, heat treatment and finishing steps, need to strictly control the processing parameters and process flow.
• Surface treatment process: Surface treatment process is an important means to improve the corrosion resistance and beauty of the valve body. Different surface treatment processes are suitable for different use environments and media conditions.

To sum up, the casting or processing of the copper ball valve body is a complex and fine process, which requires strict control of the process parameters and quality requirements of each link to ensure the performance and quality of the final product.
